Customer: Bechtel International Inc.

Owner: Chevron Australia Pty. Ltd.

Location:  Western Australia

Steel Material Standard: Chinese GB

Fabrication Code: AISC & AWS D1.1

Total Tonnage:  16,407 MT

Whole Project Duration:  Dec.2013~Dec.2015

Fireproofing Tonnage:  2,800 MT

Fireproofing Area:  2,1000 m2

Fireproofing Material: Epoxy Intumescent Paint

Fireproofing Standard: J-30 jet fire rating and a 2 hour rating in accordance with a hydrocarbon pool fire test.

Fireproofing Code: API 2218, ISO-22899-1, UL 1709, Lloyds Register Certificate of Approval, # SAS F110299/M1 standard.

Fireproofing Duration:  Jan.2015~Aug.2015

USSL Project No.: 9000

Project Description:

Wheatstone LNG is an under construction liquefied natural gas plant at Ashburton North, 12 kilometres (7.5 mi) west of Onslow, Western Australia. The project is developed and will be operated by Chevron Australia Pty. Ltd. The Certificate of Appreciation was awarded to USSL and we created a successful project with our great effort.

The fire proofing work was started from Jan. 2015 and  completed by Augest, 2015. The quantity of fireproofing area is around 2,1000 m2

Fireproofing System:

- Galvanized steel shall be lightly abrasive blast cleaned in accordance with SSPC-SP 16.

- Tie coat: Intergard 269; 40um.

- Fireproofing Paint: Chartek 7; 9~15mm.

- HK-1 mesh.

- Top Coat: Interthane 990; 50umx 2 coats.
